SECTION 3, Page 32 SJIII Series - The Conventionals 129919
Figure 3.5-1b. Electrical Schematic - ANSI/CSA Models Equipped With No Options
A B C D E F G H
M132455AE
V
Z
Y
X
W
Serial Breakdown Reference Chart
Model Serial Number
3220 60001416 & Above
3226 27004130 & Above
46XX 70004266 & Above
Refer to following page(s) to locate model,
serial number and respective diagram.
Figure 3.5-1a
AI
