SKYJACK, Page 78
February 2008
Mid Size & Full Size RT’s
Engine Powered
Section 2 - Operation Labels
No. Label Pictorial Description
5
Raise Platform
Select to raise platform.
6
Lower Platform
Select to lower platform.
7
Winching/Towing/Pushing Procedure
Winching/towing/pushing procedure. Ensure brake is released
and free-wheeling valve is open before moving the aerial platform
manually.
Electrical Panel and Hydraulic/Fuel Compartment (Continued)
765
