HB600-24B CHARGER MANUAL 06JAN2009
- 11 –
the charger operates properly on other AC outlets, a qualified person should correct the AC
circuit problem. If the AC supply checks good, the charger should be replaced.
Note: Over 1/2 of all battery chargers returned as "failed" are good. Please follow the
troubleshooting procedures carefully and check all other items before returning the
charger as failed.
Replacing the Charger
Replace only with charger designed for use with the batteries and machine to ensure
compatibility with all machine systems. Make sure the charger is unplugged before replacing
and be careful tools do not short battery connections which can cause electric sparks. Ensure
connections are the same as the original charger with wires connected by a qualified person
(see tag on AC cord):
AC Ground – green with yellow stripe
AC Neutral – light blue
AC Line (Hot) – brown
DC Battery Negative (-) – black
DC Battery Positive (+) – red
Interlock wires - White and black
Make sure all connections are clean and tight to provide a good electrical connection. Check
all machine operating systems after replacement to ensure proper operation (see manual).
WARNING:
Disconnect from AC voltage before doing any service. When
plugged-in the AC wiring is an electric shock hazard. Disconnecting the DC output
wires near the batteries when the charger is ON may cause arcing and the batteries
to explode resulting in serious injury or death.
WARNING:
Risk of an electric shock causing serious injury or death. Do not
touch un-insulated parts of the charger wires, battery connector or battery terminals.
Be careful with tools as shock or arcing from shorting of electrical parts can cause
serious injury or death. Remove rings, watches, and jewelry to avoid arcing and
electric shock.
WARNING: Do not disassemble the charger. Take it to a factory-authorized
service agent when service or repair is required. High voltages inside the charger
are an electric shock hazard and can result in serious injury or death.
