HB600-24B CHARGER MANUAL 06JAN2009
- 8 –
Maintenance
1) All electrical connections must be kept clean and tight. Sometimes connections can
look good outside but be corroded inside causing an output connection error (one flash
failure, see troubleshooting).
2) The charger cools through the case fins. If the fins become covered with debris the
charger’s over-temperature protection system may reduce charging power. Clean-off
fins to improve cooling.
3) Replace the charger if case damage breaks the water-tight seal.
4) Inspect wiring weekly, including AC plug, AC cord, DC wires to battery, and interlock
wires for cut insulation, pinching, or other damage. Repair to avoid electric shock.
AC Ground – green with yellow stripe
AC Neutral – light blue
AC Line (Hot) – brown
DC Battery Negative (-) – black
DC Battery Positive (+) – red
Interlock wires – black and white
5) Follow battery supplier recommendations for battery care and maintenance.
Note – most battery charging problems relate to battery care and not charger
problems.
WARNING:
Disconnect from AC voltage before doing any service. When
plugged-in the AC wiring is an electric shock hazard. Disconnecting the DC output
wires near the batteries when the charger is ON may cause the batteries to explode
resulting in serious injury or death.
WARNING:
Risk of an electric shock causing serious injury or death. Do not
touch un-insulated parts of the charger wires, battery connector or battery terminals.
Be careful with tools as shock or arcing from shorting of electrical parts may cause
serious injury or death. Remove rings, watches, and jewelry to avoid arcing and
electric shock.
