Page 40 December 2007
SJ 46A & SJ 46AJ
Function Tests Section 2 - Operation
Test Driving Speed•
1. Depress and hold footswitch.
2. Raise “
” main boom 4 ft. (1.2 m)
above ground and then slowly move drive/
steer controller to full drive position.
Result: The maximum achievable drive
speed should be significantly less than
stowed drive speed.
3. Lower boom to stowed position.
4. Extend “
” fly boom approximately
12 in. (30 cm) and then slowly move drive/
steer controller to full drive position.
Result: The maximum achievable drive
speed should be significantly less than
stowed drive speed.
5. Retract fly boom.
6. Raise riser approximately 4 ft. (1.2 m)
above ground.
Result: The maximum achievable drive
speed should be significantly less than
stowed drive speed.
Drive/Steer
Controller
Horn
Engine start/on/off
Switch
