Page 80 Mid Size & Full Size RTs
Engine Powered
No. Label Pictorial Description
6
Winching/Towing/Pushing Procedure
Winching/towing/pushing procedure. Ensure brake is released
and free-wheeling valve is open before moving the unit manually.
7
Base Controls
Select “
” to lower or “ ” raise platform.
Select “ ” platform to enable platform controls, “ ” off to
disable controls or “ ” base to enable base control console.
Push “ ” to disable controls.
8
Emergency Lowering Procedure
In case of emergency, follow procedure outlined in label to lower
the platform.
9
Standards Compliance
Indicates standards to which aerial platform complies.
Electrical Panel and Hydraulic/Fuel Compartment (Continued)
1
54
6
9
7
8
2 3
Front View Rear View
Side View
To Next Page
