33
SJ6826 RT, SJ6832 RT
221587ABA
Optional equipment Section 3 – Familiarization
5
Auto-level light: This light illuminates to show the
status of the outriggers when the automatic and
manual level functions are in use. The light has
these states:
Auto-level
light
Outrigger condition
Off
The outriggers are fully retracted. The
outriggers are not active.
Flashing
slowly
Indicates the outrigger extension or
retraction.
Flashing
quickly
The outriggers are extended and
the MEWP is not level, or there is an
outrigger or auto-level function error.
On
The outriggers are extended and the
MEWP is level. The light is on while
the auto-level function is active only.
3.6-4 Hydraulic generator
The hydraulic generator supplies power to the AC
power socket on the platform of the MEWP.
It is controlled by the generator switch on the outrigger
control console.
Refer to section 5.10 on how to operate the hydraulic
generator.
FAMILIARIZATION
