Skyjack SJ6832 RT - Engine Compartment

84
SJ6826 RT, SJ6832 RT
221587ABA
Section 8 – Labels Engine compartment
Description Label Pictorial
1
Base control console
▪
Push to reset ground circuit breaker.
▪
Push to reset power circuit breaker.
▪
Push to stop engine and disable controls (emergency-stop).
▪
Light indicates controls enabled.
▪
Push and hold to start engine.
▪
Push and hold to operate choke (dual fuel) or glow plugs
(diesel).
▪
Select gasoline or propane. Light indicates glow plug operation
(diesel).
▪
Select to raise or to lower platform.
▪
Select to enable platform controls, to allow engine run with no
controls active or to enable base control console.
▪
Read the operating manual.
TM
2
Positive air shutoff (optional equipment)
Select the positive air shut-off switch (optional) to stop the air
supply to the engine.
1
2
8.1 Engine compartment
