Rough Terrain Scissors
December 2007 Page 83
No. Label Pictorial Description
21
Base Controls
Select “ ” to lower or “ ” raise platform.
Select “ ” to enable lift.
Push “ ” to disable controls.
22
Emergency Lowering Procedure
Refer to operating manual.
1. Turn main power disconnect switch to off position.
2. To open the lift cylinder holding valves located at the bottom of
each cylinder:
if higher reach required, use emergency lowering rod
located on the top of the base to:
(A) push
(B) turn knurled knob counterclockwise.
3. To lower the platform, pull out emergency lowering valve
located on the outside of the hydraulic tray.
23
Lift and Tie Down Points
Only use these points for lifting or tying down.
24
Fuse Location
Fuse location
25
PROPANE
Propane
Indicates propane storage location.
