Introduction
· 02
D100 V2
Please read this entire operating manual completely and attentively before
using this product, as it covers a wide range of information on operating and
safety. Or please do use this product in company with a specialist!
LCD Display
Output Socket
4mm Banana Plug
Balance Lead Socket
Temperature
Sensor Port
USB Port
Micro USB Port for
PC Link /
firmware upgrade
Temperature
Sensor Port
Output Socket
4mm Banana Plug
Balance Lead Socket
Cooling Fan
AC Input
100-240V
Switch from
Channel A to B or
Channel B to A
Resume or Start
Charge Processes
DC Input: 11-18V
DC Output: 13.8V
DC Power
LED Light
Scroll Through the
Main Menu Stop Any
Charge Processes
Alter Values
See the Status of Individual
Cells in Balance Charge Mode
Speaker System
