10
Fuel cock
Air cleaner
Battery & fuse
Shock absorber, rear
Helmet lock
Lever Assy, gear shifting
Foot rest
Stand, prop
Lever, choke
CONTROLS
KEY
This motorcycle is equipped with a pair of identical ignition keys. Keep the spare key in a safe place.
IGNITION SWITCH
There are two positions for ignition switch:
"OFF" position
All electrical circuits are disconnected.
" "position
The ignition circuit is connected and the engine can be started.
INSTRUMENT PANEL
SPEEDOMETER
The speedometer indicates the driving speed in kilometers per hour.
ODOMETER
The odometer keep the record of the total distance that the motorcycle
has run since it was used.
NEUTRAL INDICATOR LIGHT
When the transmission is in neutral position, the green neutral indicator
light comes on. When the transmission is not in neutral, the indicator
won't flash.
11
