13
STEP 14
Congratulations on completing your new geo dome! (See... we knew you could do it!) So here comes the real
question... are you satisfied with this completed product? If you are, go ahead and write a review on the
retailer’s site you bought it from. We’d really appreciate it... and if we could, we’d give you a gold star. Are you
completely frustrated and have some choice words for us? Contact us directly! We’re not trying to ruin your life,
we promise. And we’ll do everything we can to make it right again. See contact info on page 2-3.
9
M10 Nut
(x1)
M10 Washer
(x2)
11
10
Last step! Connect the top of the geo dome by placing
a M10X33mm bolt [9] through all five tube 4’s from the
previous step. Secure with two M10 washers [10] on either
side and a M10 nut [11]. [You will need two people for this
step, one person inside the geo dome to place bolt and
washer and one person outside the geo dome to place
the second washer and to secure the nut.
Finally, tighten all the nuts of the geo dome.
STEP 13
M10X33mm Bolt
(x1)
(10) (11)
(9)
(10)
(10)
(11)
(10)
(9)
(4)
(4)
(4)
(4)
(4)
