10
ASSEMBLY
STEP 7
Place the jump mat (5) on clear ground inside the frame. Make sure the 2 warning decals align with 2 T-joints!
STEP 8
You may want to use gloves for this step! Before you begin, make sure
each V-ring has been threaded through the holes on the enclosure
net. Make sure the enclosure door is lined up with a T-joint. Using the
spring tool, hook the smaller end of a spring into the V-ring just left of
the enclosure door. Stretch the free end of the spring until it reaches the
frame hole just left of the T-joint.
Springs (x1) Spring Tool (x1)
8
16
(16)
First V-ring
First hole
T-joint
Enclosure door
T-joint
Warning label
Warning label
Enclosure door
T-joint
To Next Page
