Skywalker STRC915.2 - Step 13: Attach Initial Springs; Step 14: Attach Big Springs

ASSEMBLY
Attach four big springs (11) to the middle of a middle frame tube (7). Repeat
this step to attach four big springs on each of the remaining middle frame
tubes.
You should now have 16 big springs placed, and 16 regular springs placed
for a total of 32 springs.
14
STEP 14
11
Big Spring (x16)
You may want to use gloves for this step! Using the spring tool (26), hook
the smaller end of a spring (10) into the V-Ring that’s just left of a corner
D-ring. Stretch the free end of the spring until it reaches the nearest frame
hole on the corner tube (1). Repeat this step to attach four springs on each
corner. You should now have 16 springs placed. Note: Do not place springs
on the corner D-rings or in the spring holes closest to the corner yet.
STEP 13
Spring (x16)
26
Spring Tool
(x1)
10
(26)
Enclosure door
(1)
(11)
(11)
