Skywalker STRC915.2 - Step 23: Insert Remaining Enclosure Poles; Step 24: Insert End Caps

19
STEP 23
STEP 24
Insert the end caps (24) into the bottom of the sockets.
End Cap (x8)
24
Starting from the enclosure door, lift one of the assembled poles and insert the straight tube (13) into the
socket. Repeat this process to insert the seven remaining poles.
Helpful tip: When inserting the enclosure poles, pull back on the middle of the poles!
Socket
Pull back
(24)
