Skywalker STRC915 - Parts List

23
PARTS LIST FOR TRAMPOLINE
* These parts are not illustrated.
Specifications are subject to change without notice.
Key
No. Qty. Description
1 4 Frame tube 9 4 Female tube
2 8 Socket 10 8 Leg Extension
3 16 M10X88 Bolt 11 20 M6 X70mm Bolt
4 16 M10 Nut 12 20 M6 Nut
5 16 M10 Washer 13 40 M6 Washer
6 2 Right corner tube(2) 14 4 Middle tube
7 2 Left corner tube(2) 15 1 Mat
8 4 Male Curved tube 16 76 Spring (include 60 small spring and 16 big spring)
17 2 Pad
Key
No. Qty. Description
5
13
14
15
16
16
17
217
211
212
216
218
2112
219
2110
2111
213
214
