Skywalker SWST12D09 - Part Identification

4
Before you begin, take a look at the drawings below to make sure you have all the parts! The numbers in the squares
to the left (key numbers) will help you identify the parts during assembly.
PART IDENTIFICATION
1 2
3
4
5
6
7
8
T-joint (may be pre-
installed) (x6)
Socket (may be
pre-installed) (x6)
Leg Extension (x12)
Leg Brace (x6)
Jump Mat (x1) Frame Pad (x1)
Enclosure Net (x1)
Springs (x72)
9
Straight Tube (x6)
10
Curved Tube (x6)
11
Foam (x12)
12
Pole Cap (x6)
