OPTIONS
closed (must open contacts to activate the reset). Hardware and software have been
reconfigured to provide the interlock connections on pins 2 and 5 of the Remote Interface
Signal Input port. This reset scheme is designed for use with an external safety interlock
device that utilizes a "Fail-When-Open" configuration on its output interface. The
instrument can still be used without the external reset device as long as the Interlock
Connector 99-10094-01 (provided with unit) is plugged into the Remote Interface Signal
Input port. If there is nothing connected to the Remote Interface Signal Input port, to
provide a connection to the interlock (reset), then the instrument will not function. Please
refer to page 40 for further information about the remote interface.
