Page 31

Rear View

O

2

Cell cover

Mains Power Cable

RS232

Power Switch

Air Supply

Inlet

Oxygen Supply

Inlet

Fuse Holder

Cooling louvres

Exhaust port

for Exhalation

Block

& Viewlink

Connector
