Slinex ML-17HD - Table of Contents

SENSOR TYPE
1/2.9” CMOS, 1920×1080 px
VIDEO OUTPUT
AHD 1080p (2 MP), AHD 720p
(1 MP) or CVBS (PAL)
VIEW ANGLE
130˚
NIGHT BACKLIGHT
Infrared, 3 meters distance
LOCK TYPES
Electromechanical or
electromagnetyc locks with up to 6A
current
VOLTAGE
+12 V from the monitor
POWER CONSUMPTION
2.5 W in working mode
INSTALLATION TYPE
Surface mount
DIMENSIONS
48×133×21 mm
WORKING TEMPERATURE
–40 ... +50 ˚C
ML-17HD
3 4
Table of contents
1. Package .......................................................................................................................... 4
2. Specication ................................................................................................................. 4
3. Description.................................................................................................................... 5
4. Schematic diagram .................................................................................................... 7
5. Installation..................................................................................................................... 8
6. Video camera output setting (AHD or PAL)....................................................... 10
7. Limited Warranty......................................................................................................... 11
1. Package
ML-17HD outdoor panel − 1 pc.
Wall mounting bracket − 1 pc.
Angle bracket (optional)− 1 pc.
Mounting screws and anchors − 1 pkg.
User manual − 1 pc.
2. Specication
