4. Specifications
Technical
Network Bandwidth
100M
Transmission
Distance
100m CAT 5E/6/6A/7
Control Ports
2 x 100M LAN [RJ45 connector] [VIDEO LAN support POE]
1 x IR IN [3.5mm audio jack, 12V level]
1 x DIGITAL I/O [6-pin 3.81mm phoenix connector]
1 x RS-232 [3-pin 3.81mm phoenix connector]
Dimensions
204mm(W)×98mm(D)×21mm(H)
Housing
Metal Enclosure
Color
Black
Weight
509g
Power Supply
12V/1A
Power Consumption
4.5W
Operating
Temperature
0°C ~ 40°C / 32°F ~ 104°F
Storage
Temperature
-20°C ~ 60°C / -4°F ~ 140°F
Relative Humidity
20~90% RH (non-condensing)
5. Operation Controls and Functions
5.1 Front Panel
POWER STATUS
RESET
1 2
3
