4.1 Confirmation before installation
1) Door material: Security door, gate, wooden door, glass door.
2) Door thickness: 60mm/70mm/80mm (The door thickness less than 60mm/70mm/
80mm can also be installed, but some parts of the lock core will be exposed, not
beautiful, if it exceeds 60mm, it can't be installed).
Note: 60mm/70mm/80mm is the total thickness of the door and the original lock's
front and rear panels.
If the key hole is too close to the door frame, it cannot be installed.
NO
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
Model
Basic function
Type of finger print sensor
Fingerprint capacity
App user
False recognition rate
Rejection rate
Contrast speed
Code button
Code capacity
Key press resistance
Voice hint
Power supply
Urgent power supply
Low pressure alarm
Working currency
Quiescent currency
Working temperature
YL-73
Fingerprints, Phone App, Keypad Password, Mechanical Keys
Semiconductor module
100 fingerprints
1 Administrators and 500+ authorized users
<0.001%
<1%
1:N<7s/fingerprint
12 keys, Capacitive Touch button, LED Backlight
32 Sets of 6-digit Passwords
100000 times
English
3pcs AAA Alkaline battery (Please use authentic alkaline batteries)
5V Micro USB port
3.6V±0.2
125mA (Max)
22uA
-20----45℃
3.Technical Specification
Item
specification
4.Installation instructions
4
