Helpful hints 10!5
Fuses
Fuse assignment
No. Consumers Amperage Colour
1 Starter 25 A Neutral
2 Windscreen wipers, washer pump 20 A Yellow
3 Heater blower, seat heater 20 A Yellow
4 Power windows, l. & r. 30 A Green
5 Light switch 7.5 A Brown
6 Parking lights/tail lights, r. 7.5 A Brown
7 Parking lights/tail lights, l. 7.5 A Brown
8 Terminal 87/3 master relay (engine) 20 A Yellow
9 Terminal 87/2 master relay (engine) 10 A Red
10 Terminal 87/1 master relay (engine) 15 A Blue
11 Instrument cluster, safety cluster, OBD 7.5 A Brown
12 Radio CD, interior light 15 A Blue
13 Fog lamps 15 A Blue
14 esp valves 25 A Neutral
15 Charge air cooler 15 A Blue
16 Electric fuel pump 10 A Red
