10!6 Helpful hints
Fuses
17 Rear window wiper 15 A Blue
18 Airbag triggering device, esp 7.5 A Brown
19 Mirror adjustment 7.5 A Brown
20 Radio, CD, instrument cluster, tachometer, OBD, backup lamp 15 A Blue
21 Power socket 15 A Blue
22 Low beam light, r. 7,5 A Brown
23 Low beam light, l. 7,5 A Brown
24 High beam light, r. 7.5 A Brown
25 High beam light, l./combined light 7.5 A Brown
26 Brake light 15 A Blue
27 Engine control unit 7.5 A Brown
28 Rear window heater/engine fan 30 A Green
29 Soft top 30 A Neutral
30 Manual gearbox 40 A Orange
31 Horn, central locking, rear lid remote unlocking 30 A Green
32 Secondary!air pump 30 A Green
33 Ignition 50 A Red
No. Consumers Amperage Colour
