USER’S MANUAL PAGE 11WBC-200
Digital display LED indicator Charging state
CHARGING CHARGING LED lit
The charger is
charging the battery.
CHARGED
CHARGED/
MAINTAINING LED lit
The battery is fully
charged.
MAINTAINING
CHARGED/MAIN-
TAINING LED lit
The charger is
maintaining the
battery.
BATTERY TYPE BUTTON
Digital display LED indicator Description
CHARGING
6V / 12V
STD LED lit
Charging 6V and 12V WET/MF/EFB
batteries. During charging, pressing
BATTERY TYPE button is void.
CHARGING
6V / 121V
AGM LED lit
Charging 6V and 12V AGM batteries.
During charging, pressing BATTERY
TYPE button is void.
CHARGING
6V / 12V
GEL LED lit
Charging 6V and 12V GEL batteries.
During charging, pressing BATTERY
TYPE button is void.
RATE SELECTION BUTTON
6<>2A CHARGE/MAINTAIN (press RATE SELECTION button once to enter
based on OFF mode) – For charging small and large batteries. Not recom-
mended for industrial applications. For 12V type battery, if battery voltage is
over 13.5V, the maximum output is 2A instead of 6A; for 6V type battery, the
maximum output is 2A.
After testing the battery, the charger will go into the OFF mode. You can
choose the following option to make your desired selection. In order to come
back to OFF mode, you need to press the ENGINE START / RATE
SELECTION button once while you are in other modes.
