USER’S MANUAL PAGE 9WBC-200
CHARGER TECHNICAL SPECIFICATIONS
AC Input 120VAC, 60Hz, 9.8A Maximum continuous, 48A
MAXIMUM INTERMITTENT.
DC Output Charge: 6/12VDC, 2A-120 Seconds,
6A-60 Seconds
Boost: 6/12VDC, 40A Continuous
Engine Start: 12VDC, 200A Intermittent 5 Seconds
On, 240 Seconds Off.
Temperature Controlled
Charger Type 4 step, Fully automatic charging cycle
Start Voltage > 1V
Housing Protection IP20
Battery Type All Types of 6V and 12V Lead-acid Batteries
Battery Capacity 4-450Ah (6V/12V) Maintains all battery sizes
Accessories
Included
Clamp Connectors
Ambient
Temperature
32˚F – 104˚F (0˚C – 40˚C)
DISPLAY MESSAGES
Startup – Display screen and all LEDs illuminate for 0.5 second.
“SMARTECH” text will scroll across the display twice followed by
“NO CONNECT” text (if nothing is connected to the charger).
TESTING is shown on digital screen, battery voltage shows (meanwhile
battery VOLTAGE LED is lit).
