USER’S MANUAL PAGE 17WBC-200
ENGINE START FUNCTION
Your battery charger can be used to jump start your car if the battery is
low. Follow all safety instructions and precautions for charging your battery.
Wear complete eye protection and protective clothing. The procedures are
as follows.
During the 12V battery type charging process, the charger performs the
following operations.
STEP 1 – IDENTIFY VOLTAGE Determines if the connected battery is 6V
or 12V
STEP 2 – MULTI CYCLICAL CHARGE Charges the battery with two kinds
of cyclical constant current
STEP 3 – ABSORPTION Provides constant small current charge for
absorption
STEP 4 – MAINTENANCE Analysis and maintaining process, the output
current is 0.5A for 1S, 1.5A for 1S, 0.5A for 1S, 1.5A for 1S . . . repeat.
Voltage
(V)
Current
(A)
1 2 3 4
