smartflower POP - Truck;Transportation Conditions

02
11
LOADING & PACKING
Truck/transportation
conditions
Loading ONLY from aside position possib-
le!
(facing truck from lateral direction)
Required truck loading platform clea-
rance from sideward position: min 2.68 m
(important note: product height inclu-
ding packaging material is 2.65 m!)
Fixation with anti-slide protection is
mandatory!
Loading
height
from side
min.
2680 mm
Loading
height
from side
min.
2680 mm
Fixation
bolts
Truck floor
Truck roof
Truck floor
Truck roof
LOADING REQUIREMENTS
Belt position
Transportation guide
Fit 4 pcs anti slide
each product
Additional protection
for belt tensioner
Anti-collission
spacer
Belt position
Transportation guide
2 pcs wooden bars
(5x8x900) outside
Fit 1pc woodenstick
(10x10x900) between Pop’s
Fit 4 pcs anti slide
each product
Additional protection
for belt tensioner
Anti-colission spacer
two products side by side single product
