LOADING & PACKING
REUSABLE PARTS
The following parts are primarily used for
transportation and installation purposes.
Please store them for cases of further
installations.
Anti-collissions spacers
Transportation guide / crane hook
1
2
Accessory parts
Spacers are
used as
mounting
brackets
fixation of
the product
with screw
foundation.
ACCESSING THE ACCESSORY PARTS –
HOW TO REMOVE THE REAR COVER DOME?
1
open/remove 2 screws
from upper cover (size 19 mm hex bolts)
2
lift dome first 5–10 cm up
and then remove rearwards (the bottom
of the cone is guided with 2 pins)
To Next Page
