Indicators and slots
Front panel
Element Purpose
Power
indicator
Green — STB is switched on and operates normally.
Red — STB is in the stand-by mode.
IR receiver The internal IR receiver is accepting signals from the IR
remote control.
Back panel
Element Purpose
DC 12V The port for a power adapter
A/V The analog audio/video interface (composite + stereo audio
signal)
S/PDIF Optical digital audio interface
