Error Code Display
If there is something wrong with the electronic
control system, the display will show the error code
automatically (see below for codes). Should you
receive an error code, contact your local dealer for
advice.
【33【CURRENT ABNORMAL
【34【THROTTLE ABNORMAL
【35【MOTOR ABNORMAL
【36【HALL ABNORMAL
【37【TEMPERATURE ABNORMAL
【38【CONTROLLER COMMUNICATION ERROR
【39【LOW VOLTAGE
【09【COMMUNICATION DISPLAY RECEIVING ERROR
Before contacting service center check all plugs for
loose connections.
8. Display Panel Controls
USB Output Charging
Hold and for 2 seconds and the USB
symbol lights to detail that the user can now charge
phone, etc, via the USB output port which is on the
underside of the lcd, under a rubber waterproof
plug. Make sure the plug is reinstalled after
charging.
SET
SET
Wheel Size
Select the suitable value to ensure the accuracy of
display about speed and mileage.
KPH and MPH
Select MPH or KMH for the speed and mileage,
display will be the currently selected units display.
Press or to select parameter, hold for
1 second to save and exit.
9. Frame lock and Seatpost
Frame Lock
The SmartMotion eUrban has been upgraded with
an integrated frame lock. Your new bike will come
with a set of keys for the battery lock and a set
of keys for the frame lock. Make sure you keep a
master key from each in a safe place so you can
always get more copies made.
Suspension Seatpost
The SmartMotion comes with a suspension
seatpost. For optimum performance you need
to set the preload so when your weight is fully
on the seat the spring is depressed about 30-
40%. Test the travel, then, if you need to adjust,
remove the seatpost and, with a 5mm allen key,
screw the shock up into the seatpost to increase
spring pressure, or back down to reduce it.
Your dealer can also set this up for you.
The bike has been tted with a quick release
seatpost collar to facilitate changing the riding
position.
It is important that the nut on the collar is
tightened so the post will not move in the bike
frame.
Make this adjustment with the quick release
lever in the open position.
Adjust the seat to the correct height and close
the lever. When you sit on the saddle there
should be no vertical movement at all in the
seat post below the suspension.
