3. Seat
Release the seat post clamp lever and set the
seat post height to the position which is suitable
for you to comfortably reach the ground when
you are sitting on the bike, then refasten the
seat post clamp. The maximum height should be
within the max height markings on the seatpost.
4. Pedals
Attach the pedals to the cranks, paying attention to
the markings on the axle. The pedal with markings
is the left pedal. Note: the pedals have opposing
threads – screw in the left pedal counterclockwise
and screw in the right pedal clockwise. Install
L pedal counterclockwise and the right pedal
clockwise.
2. Assembly Instructions
