5. Front wheel
Carefully lift the bike front forks off the ground
and lower the forks onto the wheel axle, being
careful the disc rotor fits correctly into the disc
calipers (this job is best with 2 people). Slide the
axle through from the left side. Tighten the non-
rotor side nut finger tight and try to close the quick
release lever. Loosen or tighten the nut until it takes
the correct amount of force to close the lever. It
should be hard to close, but not so hard you cannot
fully close it. It must fully close (as in picture)
otherwise the wheel may come loose, causing
serious injury. Note: if you are not well trained in
cycle assembly, this procedure must be checked by
a cycle technician.
2. Assembly Instructions
