Location Part # Description
1 NC1037 Replacement Top Shell (Avail. In Charcoal Grey Only)
2 NC1009:02 Pump Motor (NC2x)
3 NC1013 Power Supply (NC2x)
4 NC1012SK Anti-Twist Floating Cord 40' (NC2x)
5 NC1006T:02 Drive Motor Assembly - Tan (NC2x)
6 NC1010T Drive Tube Mount - Tan (NC2x)
7 NC1011 Top Shell Bumper
8 NC1002 Sensor Wheel Tire
9 NC1005 Quick Drain Flap
10 NC1017 Filter Bag
11 NC1003 Replacement Impeller Cover (Avail. In Black Only)
12 NC1008 Handle incl. Screws
13 NC1004 Drive Brush (Set of 2)
14 NC1014 Foam Ring
15 NC1007 Drive Wheel Tube
16 NC1016 Replacement Bottom Lid - Black Only
17 NC1018 Front Intake - incl. Fur and Srping
18 NC1019 Rear Intake - incl. Fur and Spring
19 NC1015 Replacement Impeller - Black Only
20 NC10341T Front Fender - Tan (NC2x)
21 NC1001:02 Chassis with Senser Wheels
