9
．
Dimensions
Model
Standard specifications
Port size A C D E1 E2 G H J
1(P) 2(A) 3(R)
AV2000-□02-1 to 4G(Z)□-A 1/4 1/4 1/4
66 47 24.5 20 20 33
Width across
flats 22
30
AV2000-□02-5 to 6G(Z)□-A 1/4 1/4 1/4
AV3000-□03-1 to 4G(Z)□-A 3/8 3/8 3/8
76 50 29.5 20 20 38
Width across
flats 24
35
AV3000-□03-5 to 6G(Z)□-A 3/8 3/8 3/8
AV4000-□04-1 to 4G(Z)□-A 1/2 1/2 1/2
98 56 39.5 26 26 49
Width across
flats 30
33
AV4000-□04-5 to 6G(Z)□-A 1/2 1/2 1/2
AV5000-□06,10-1 to 4G(Z)□-A 3/4,1 3/4,1 3/4
128 59 53 37 37 53
Width across
flats 36
52
AV5000-□06,10-5 to 6G(Z)□-A 3/4,1 3/4,1 3/4
Grommet: AV□00-□-□G□-□-A
Body
size
Coil
type
B
20
AC 85
DC 83
30
AC 85
DC 83
40
AC 95
DC 93
50
AC 98
DC 96
(mm)
(mm)
Model
Optional specifications
With bracket With built-
in silencer
K L M N P Q R S T U V W X Y
AV2000-□02-1 to 4G(Z)□-A
30 50 51.5 44 5.5 10 66 2.3 33.5 54 －
M4 x 0.7
Depth 6
3
Width across
flats 14
AV2000-□02-5 to 6G(Z)□-A
AV3000-□03-1 to 4G(Z)□-A
41 50 53.5 46 5.5 15 70 2.3 33.5 54 ―
M4 x 0.7
Depth 6
3
Width across
flats 19
AV3000-□03-5 to 6G(Z)□-A
AV4000-□04-1 to 4G(Z)□-A
50
60 64 54 8.5 18 90 3.2 39 74 ―
M5 x 0.8
Depth 6.5
4
Width across
flats 22
AV4000-□04-5 to 6G(Z)□-A
AV5000-□06,10-1 to 4G(Z)□-A
70 75 70 60 11 16 100 3.2 45 80 56
M6 x 1
Depth 8
6
Width across
flats 32
AV5000-□06,10-5 to 6G(Z)□-A
-28-
Dimensions
