SMC Networks D-M9 Series User Manual

-19-
No.D-※S-OMJ0004-E
Contact type: Normally closed (inverted) output
Yes
No
The switch
output doesn’t
turn off.
The operation
LED doesn’t turn
off.
The operation
LED doesn’t go
on.
Is the actuator
applicable?
Product failure
Product failure
Misapplication
Trouble No.4
Product failure
Trouble No.6
The operation
LED doesn’t turn
off.
The operation
LED doesn’t go
on.
Trouble No.1
The switch
doesn’t detect
normally.
The operation
LED doesn’t go
off.
The operation
LED doesn’t turn
on.
The switch
output doesn’t
turn on.
Trouble No.2
Trouble No.3
Trouble No.5
The switch
outputs
normally.
Normal
operation
