-100-
No. DOC1045423
•Temperature measurement count unit (EX600-AT#)
Index
Name (Meaning)
Type
Value
40x0:0
Unit parameters
UNSIGNED8
19
40x0:0B
Data format
Enum080A
1 = Signed magnitude
2 = 2's complement
40x0:13
Temperature
Enum080F
0 = C (Celsius)
1 = F (Fahrenheit)
40x9:0
Filter
UNSIGNED8
4
40x9:01
:
40x9:04
Channel 0
:
Channel 3
Enum080B
0 = None
1 = 2 value average
2 = 4 value average
3 = 8 value average
40xB:0
Number of wires
UNSIGNED8
4
40xB:01
:
40xB:04
Channel 0
:
Channel 3
Enum0810
4 = 2 wires
5 = 3 wires
6 = 4 wires
Note: x = Unit No.
