SMC Networks EX600-ED Series User Manual

-101-
No. DOC1045423
•IO-Link master unit (EX600-L#B1)
Index
Name (Meaning)
Type
Value
40x0:0
Unit parameters
UNSIGNED8
19
40x0:01
Monitor short circuit (power)
Enum0800
0 = Disable
1 = Enable
40x0:0C
Fault output (IO-Link)
Enum0805
0 = Clear, PDOut valid
1 = Hold
2 = Clear, PDOut invalid
40x0:0D
Fault output (DO_CQ)
Enum0804
0 = Clear
1 = Hold
2 = ForceON
40x0:0E
Idle output (IO-Link)
Enum0805
0 = Clear, PDOut valid
1 = Hold
2 = Clear, PDOut invalid
40x0:0F
Idle output (DO_CQ)
Enum0804
0 = Clear
1 = Hold
2 = ForceON
40x0:10
Byte swap
Enum0811
0 = Direct (No Swap)
1 = Swap 16bit
2 = Swap 32bit
3 = Swap all
40x1:0
Port1 - Port configuration
UNSIGNED8
6
40x1:01
Port mode
Enum0812
0 = Deactivated
1 = IOL_Manual
2 = IOL_Autostart
3 = DI_C/Q
4 = DO_C/Q
40x1:02
Validation & Backup
Enum0813
0 = No Device check
1 = V1.0
2 = V1.1
3 = V1.1, Backup + Restore
4 = V1.1, Restore
40x1:03
1
I/Q behavior
(Pin2 function at M12 Connector)
Enum0814
1 = Digital Input
5 = Power2 (Port class B)
40x1:04
Port cycle time
UNSIGNED8
0 : As fast as possible
1 to 3 : 0.4 ms
4 to 63 : 0.4 to 6.3 ms
64 to 127 : 6.4 to 31.6 ms
128 to 191: 32.0 to 132.8 ms
192 to 255: 132.8 ms
40x1:05
Vendor ID
UNSIGNED16
0 to 0xFFFF
40x1:06
Device ID
UNSIGNED32
0 to 0x00FFFFFF
40x2:0
Port2 - Port configuration
See Port1 - Port configuration
40x3:0
Port3 - Port configuration
40x4:0
Port4 - Port configuration
