Specifications
Model
EX600-MEC1
Communication
Protocol
EtherCAT
®
(Conformance Test Record V.2.4.0)
Communication speed
100 Mbps
Configuration file
ESI file
Applicable function
Web server
Electrical
Power supply for control/input
24 VDC, Class 2, 1A (US1)
Internal current consumption
(Power supply for control/input)
170mA or less
Power supply for output
24 VDC, Class2, 2A (US2)
Valve control
Applicable manifold series
Plug-in Connector Connecting Base (64-station Compatible Manifold)
Number of outputs
128 outputs max.
Output operation at network fault
HOLD / CLEAR / ForceON
Protection
Short circuit protection (on the valve manifold)
ITV control
Applicable ITV series
Plug-in type electro-pneumatic regulator for manifold
Number of modules
4 modules max.
Protection
Short circuit protection
Environment
Enclosure
IP67 (With manifold assembled)
1
Operating temperature range
-10 to 50 °C
(Max. Surrounding Air Temperature Rating: 50 °C)
Storage temperature range
-20 to 60 °C
Operating humidity range
35 to 85% RH (no condensation)
Withstand voltage
500 VAC for 1 minute between external terminals and F.E.
Insulation resistance
500 VDC, 10 MΩ or more between external terminals and F.E.
Vibration resistance
10 to 57 Hz: constant amplitude 0.75 mm p-p
57 to 150 Hz: constant acceleration 49 m/s
2
for 2 hours in each direction X, Y, and Z respectively
(De-energized)
Impact resistance
147 m/s
2
3 times in each directions of X, Y, and Z respectively
(De-energized)
Standard
CE/UKCA marked, UL (CSA)
Weight
310 g or less
1: All unused connectors must have a seal cap fitted to maintain IP67 rating.
