-25-
No. DOC1045423
•L/A PORT-1 LED
LED display
Content
OFF
PORT-1 (BUS IN): No Link, No Activity
Green ON
PORT-1 (BUS IN): Link, No Activity (100 Mbps)
Green flickering
PORT-1 (BUS IN): Link, Activity (100 Mbps)
•L/A PORT-2 LED
LED display
Content
OFF
PORT-2 (BUS OUT): No Link, No Activity
Green ON
PORT-2 (BUS OUT): Link, No Activity (100 Mbps)
Green flickering
PORT-2 (BUS OUT): Link, Activity (100 Mbps)
