SMC Networks EX600-ED Series User Manual

-28-
No. DOC1045423
End plate
Model Indication and How to Order
EX600-ED -
End plate at D-side
Mounting method
Symbol
Description
Connector
Nil
No DIN rail bracket
Symbol
Connector
Key type
Function
3
With DIN rail bracket (for SY/JSY valve)
2
M12 (5-pin)
B-coded
IN
3
7/8 inch
(5-pin)
-
IN
4
M12
(4-pin/5-pin)
A-coded
IN/OUT
(PIN layout 1

)
5
M12
(4-pin/5-pin)
A-coded
IN/OUT
(PIN layout 2

)
: Refer to Connector Pin No. (page 31) for details of the PIN layout 1 and 2.
