■SI unit parameters (ITV related)
No.
Parameter
Definition
Item
Content
Default
setting
Parameter
setting range
1
Monitor short
circuit (power)
Generates error
when the short
circuit of the ITV
power supply is
detected.
Enable
Generates an error.

Unit
Disable
Does not generate an
error.
2
Hold/Clear
1
Sets pressure
control when
EtherCAT
®
communication
error/idling is
occurred.
Pressure Clear
Exhaust completely

Channel
Pressure Hold
Output pressure is
maintained
3
Gain
1
The response time
can be changed.
0 to 15
Gain can be adjusted in
the range from 0 to 15
9
Channel
4
Sensitivity
1
Change the
pressure
correction
operation near the
set pressure.
0 to 7
Sensitivity can be
adjusted in the range
from 0 to 7.
2
Channel
5
Minimum
pressure
1
Set the minimum
pressure (F_1).
0 to 3686
Can be set in the range
from 0 to 90%.
2
0
Channel
6
Maximum
pressure
1
Set the maximum
pressure (F_2).
410 to 4914
Can be set in the range
from 10 to 120%.
2
4095
Channel
7
Notification
setting of the
accumulated
energizing
time
1
When the
accumulated
energizing time
reaches the set
value, it is notified
on the input data
of the ITV module.
0 to
4294967295
Can be set in units of set
value × 1 hour.
If set to 0, no notification
is performed.
0
Channel
1: For more information about the parameters related to the ITV module, refer to the ITV module operation manual. (DIY-60L00-OM002)
2: Combinations of values that satisfy the following formula cannot be set.
Maximum pressure − Minimum pressure < 410
