■Digital Input/Output unit parameters
No.
Parameter
Definition
Item
Content
Default
setting
Parameter
setting range
1
Monitor short
circuit (power)
Generates error
when the short
circuit of the power
supply for the input
device is detected.
Enable
Generates an error.

Unit
Disable
Does not generate an
error.
2
Inrush current
filter
Select the over
current detection
for 100 msec after
supplying power.
Enable
Ignores inrush current.
Unit
Disable
Does not ignore inrush
current.

3
Input filtering
time
Sets the time to
ignore the input
signal change.
0.1 ms
Selects the time for
filtering.
1.0 ms
Unit
1.0 ms
10 ms
20 ms
4
Input
extension time
Sets the time to
hold the input
signal.
1.0 ms
Selects the time to hold
the input signal.
15 ms
Unit
15 ms
100 ms
200 ms
5
Monitor short
circuit (out)
Generates error
when the short
circuit of the output
device is detected.
1
Enable
Generates an error.

Unit
Disable
Does not generate an
error.
6
Restart after
output load
short circuit
Restore the setting
of short circuit
detection error
after the output
device short circuit
is cleared.
Auto
Error is automatically
cleared when the short
circuit is fixed.

Unit
Manual
Even when the short
circuit is fixed, error is
not cleared until the
power is supplied again.
7
Monitor open
circuit
Generates error
when the
disconnection of
the output device
is detected.
Enable
Generates an error.
Channel
Disable
Does not generate an
error.

8
Fault mode
2
Sets output when
communication
error is occurred.
Clear
Turn off the output

Channel
Hold
Hold the output
ForceON
Turn on the output
forcefully
9
Idle mode
2 3
Sets the output
during
communication
idling.
Clear
Turn off the output

Channel
Hold
Hold the output
ForceON
Turn on the output
forcefully
