■Analogue Input/Output unit parameters
No.
Parameter
Definition
Item
Content
Default
setting
Parameter
setting range
1
Monitor short
circuit (power)
Generates error
when the short
circuit of the power
supply for input
device or output
device is detected.
Enable
Generates an error.

Unit
Disable
Does not generate an
error.
2
Range
Sets the range of
the analogue input
or output range.
0..10 V
Select the analogue input
or output range.
1..5 V
Channel
0..5 V
1..5 V
0..20 mA
4..20 mA
3
Data format
Sets analogue data
type of the input
data sent to the
PLC and the output
data received from
the PLC.
Offset binary
Offset binary

Unit
Signed
Magnitude
Signed magnitude
2’s complement
2’s complement
Scaled
Scale conversion type
4
Filter
Sets analogue
input filtering time.
None
None
Channel
2AVG
2 value average

4AVG
4 value average
8AVG
8 value average
5
Monitor over
range
Generates error
when the input
value exceeds
0.5% of full span.
Enable
Generates an error.
Unit
Disable
Does not generate an
error.

6
Monitor under
range
Generates error
when the input
value falls below
0.5% of full span.
Enable
Generates an error.
Unit
Disable
Does not generate an
error.

7
Monitor upper
limit
Generates error
when the input or
output value
exceeds the user
setting value.
Enable
Generates an error.
1
Channel
Disable
Does not generate an
error.

Scale setting
value upper
limit
Sets the scale
upper limit.
Generates error
when the input or
output value
exceeds the upper
limit.
Enable
Generates an error.
Value: -32766 to 32767
Disable
Does not generated an
error.
Value: -32766 to 32767

Value:
1000
