SMC Networks EX600-ED Series User Manual

-67-
No. DOC1045423
Settable range for user set upper or lower limit and output value at communication error and idling
Range
Settable range for user set upper or lower limit
Settable range for output value
at communication error
Lower limit
Upper limit
0..10 V
0.00 to +10.45 V
+0.05 to +10.50 V
0.00 to +10.50 V
0..5 V
0.00 to +5.22 V
+0.03 to +5.25 V
0.00 to +5.25 V
1..5 V
+0.75 to +5.22 V
+0.78 to +5.25 V
+0.75 to +5.25 V
0..20 mA
0.00 to +20.90 mA
+0.10 to +21.00 mA
0.00 to +21.00 mA
4..20 mA
+3.00 to +20.90 mA
+3.10 to +21.00 mA
+3.00 to +21.00 mA
Correspondence table for user set upper or lower limit and output value at communication error and idling
(Via CoE object /Web server)
(Data format: Offset Binary /Signed Magnitude /2’s Complement)
Range
Set Value
(Offset Binary Signed Magnitude 2’s Complement)
Expected value
0..10 V
CoE/Web
0 to 1050
0.00 to +10.50 V
0..5 V
CoE/Web
0 to 525
0.00 to +5.25 V
1..5 V
CoE/Web
75 to 525
+0.75 to +5.25 V
0..20 mA
CoE/Web
0 to 2100
0.00 to +21.00 mA
4..20 mA
CoE/Web
300 to 2100
+3.00 to +21.00 mA
Note: When the data format is a type other than scale conversion, input the desired voltage or current × 100 in decimal system.
