Details of diagnostic data
Byte
Bit No.
Diagnostic content
Type
0
0
The analogue input or output value has fallen below the user set limit value.
System
1
The analogue input or output value has exceeded the user set limit value.
2
The analogue input value has fallen below the setting range.
3
The analogue input value has exceeded the setting range.
4
The ON/OFF counter has exceeded the user-set limit value.
5
The open circuit has been detected.
6
The short circuit of the valve output or digital output has been detected.
7
The short circuit of the power supply for the input/output device has been detected.
1
0
The power supply voltage for output device is outside of the specification.
System
1
The power supply voltage for control and input device is outside of the specification.
2
Reserved
3
There is a disconnection between each unit (During operation).
4
There is a connection failure between each unit (When the power supply is applied).
5
Diagnosis of SI unit (ITV) is generated.
6
Internal memory error has occurred (When the power supply is applied).
7
Internal memory error has occurred (During operation).
2
0-7
Reserved
System
3
0
Diagnosis of digital input unit is generated.
System
1
Diagnosis of digital output unit is generated.
2
Diagnosis of analogue input unit is generated.
3
Diagnosis of analogue output unit is generated.
4
Diagnosis of SI unit (Valve) is generated.
5
Diagnosis of IO-Link master unit is generated.
6
Diagnosis of SI unit (ITV) is generated.
7
Reserved
4
0
There is an error in unit 0.
Unit
1
There is an error in unit 1.
2
There is an error in unit 2.
3
There is an error in unit 3.
4
There is an error in unit 4.
5
There is an error in unit 5.
6
There is an error in unit 6.
7
There is an error in unit 7.
5
0
There is an error in unit 8.
Unit
1
There is an error in unit 9.
2-7
Reserved
: SI unit error detection is assigned two unit numbers: ITV module error (SI unit number) and valve error (SI unit number +1).
Even if the “SI unit data size setting switch (ITV module)” is set to “No ITV modules” (the switch 3 of the setting 1 switch is ON), a
valve error will occur in SI unit number +1.
Note: The data of diagnostic content: 0 means No error and 1 means Error.
