-93-
No. DOC1045423
•Digital input unit (EX600-DX###)
Index
Name (Meaning)
Type
Value
40x0:0
Unit parameters
UNSIGNED8
19
40x0:01
Monitor short circuit (power)
Enum0800
0 = Disable
1 = Enable
40x0:05
Inrush current filter
Enum0800
0 = Disable
1 = Enable
40x0:09
Input filtering time
Enum0806
0 = 0.1 ms
1 = 1 ms
2 = 10 ms
3 = 20 ms
40x0:0A
Input extension time
Enum0807
0 = 1 ms
1 = 15 ms
2 = 100 ms
3 = 200 ms
40x1:0

Monitor open circuit

UNSIGNED8
Number of Channels
40x1:01
:
40x1:08
Channel 0
:
Channel 7
Enum0800
0 = Disable
1 = Enable
40x2:0
Monitor counter limit
UNSIGNED8
Number of Channels
40x2:01
:
40x2:10
Channel 0
:
Channel 15
Enum0800
0 = Disable
1 = Enable
40x3:0
Counter limit value (1-65000k)
UNSIGNED8
Number of Channels
40x3:01
:
40x3:10
Channel 0
:
Channel 15
UNSIGNED16
1 to65000
: Applicable to the open detecting digital input unit (EX600-DX#C1)
Note: x = Unit No.
