SMC Networks EX600-ED Series User Manual

-96-
No. DOC1045423
•Analogue input unit (EX600-AX#)
Index
Name (Meaning)
Type
Value
40x0:0
Unit parameters
UNSIGNED8
19
40x0:01
Monitor short circuit (power)
Enum0800
0 = Disable
1 = Enable
40x0:03
Monitor over range
Enum0800
0 = Disable
1 = Enable
40x0:04
Monitor under range
Enum0800
0 = Disable
1 = Enable
40x0:0B
Data format
Enum0808
(EX600-AXA)
0 = Offset binary
1 = Signed magnitude
2 = 2's complement
Enum0809
(EX600-AXB)
0 = Offset binary
1 = Signed magnitude
2 = 2's complement
3 = Scaled
40x5:0
Monitor upper limit
UNSIGNED8
Number of Channels
40x5:01
:
40x5:04
Channel 0
:
Channel 3
Enum0800
0 = Disable
1 = Enable
40x6:0
Upper limit value
UNSIGNED8
Number of Channels
40x6:01
:
40x6:04
Channel 0
:
Channel 3
UNSIGNED16
0 to 0xFFFF
40x7:0
Monitor lower limit
UNSIGNED8
Number of Channels
40x7:01
:
40x7:04
Channel 0
:
Channel 3
Enum0800
0 = Disable
1 = Enable
40x8:0
Lower limit value
UNSIGNED8
Number of Channels
40x8:01
:
40x8:04
Channel 0
:
Channel 3
UNSIGNED16
0 to 0xFFFF
40x9:0
Filter
UNSIGNED8
Number of Channels
40x9:01
:
40x9:04
Channel 0
:
Channel 3
Enum080B
0 = None
1 = 2 value average
2 = 4 value average
3 = 8 value average
40xA:0
Range
UNSIGNED8
Number of Channels
40xA:01
:
40xA:04
Channel 0
:
Channel 3
Enum080D
(EX600-AXA)
0 = -10…+10 V
1 = -5…+5 V
2 = -20…+20 mA
3 = 0…10 V
4 = 0…5 V
5 = 1…5 V
6 = 0…20 mA
7 = 4…20 mA
Enum080E
(EX600-AXB)
3 = 0…10 V
4 = 0…5 V
5 = 1…5 V
6 = 0…20 mA
7 = 4…20 mA
Note: x = Unit No.
