SMC Networks EX600-ED Series User Manual

-97-
No. DOC1045423
•Analogue output unit (EX600-AYA)
Index
Name (Meaning)
Type
Value
40x0:0
Unit parameters
UNSIGNED8
19
40x0:01
Monitor short circuit (power)
Enum0800
0 = Disable
1 = Enable
40x0:0B
Data format
Enum0809
0 = Offset binary
1 = Signed magnitude
2 = 2's complement
3 = Scaled
40x1:0
Fault mode
UNSIGNED8
2
40x1:01
:
40x1:02
Channel 0
:
Channel 1
Enum0800
0 = Disable (Hold)
1 = Enable (Fault value)
40x2:0
Fault value
UNSIGNED8
2
40x2:01
:
40x2:02
Channel 0
:
Channel 1
UNSIGNED16
0 to 0xFFFF
40x3:0
Idle mode
UNSIGNED8
2
40x3:01
:
40x3:02
Channel 0
:
Channel 1
Enum0800
0 = Disable (Hold)
1 = Enable (Idle value)
40x4:0
Idle value
UNSIGNED8
2
40x4:01
:
40x4:02
Channel 0
:
Channel 1
UNSIGNED16
0 to 0xFFFF
40x5:0
Monitor upper limit
UNSIGNED8
2
40x5:01
:
40x5:02
Channel 0
:
Channel 1
Enum0800
0 = Disable
1 = Enable
40x6:0
Upper limit value
UNSIGNED8
2
40x6:01
:
40x6:02
Channel 0
:
Channel 1
UNSIGNED16
0 to 0xFFFF
40x7:0
Monitor lower limit
UNSIGNED8
2
40x7:01
:
40x7:02
Channel 0
:
Channel 1
Enum0800
0 = Disable
1 = Enable
40x8:0
Lower limit value
UNSIGNED8
2
40x8:01
:
40x8:02
Channel 0
:
Channel 1
UNSIGNED16
0 to 0xFFFF
40xA:0
Range
UNSIGNED8
2
40xA:01
:
40xA:02
Channel 0
:
Channel 1
Enum080E
3 = 0…10 V
4 = 0…5 V
5 = 1…5 V
6 = 0…20 mA
7 = 4…20 mA
Note: x = Unit No.
