SPECIFICATIONS

Model

SMC2208USB/ETH

Network Interface

USB cable with one upstream connector, USB Type A

One downstream port, RJ-45 Ethernet (10/100 Mbps)

Wiring Topology

Point-to-point connections

Access Method

USB Port: USB spec. 1.0 and 1.1

RJ-45 Port: IEEE 802.3 and 802.3u CSMA/CD

10 and 100 Mbps baseband, full and half duplex

Standards

USB Specification 1.0 and 1.1 (USB low-power device)

IEEE 802.3 Ethernet

IEEE 802.3u Fast Ethernet

System Requirements

A PC and operating system that supports the Universal Serial Bus

(Windows 98/2000/Me/XP)

Also requires device driver (included)

Size

2.5 x .5 x .5 in (at the largest point)

Weight

.25oz
